• powerful and yet lightweight - more output, more power
• DVS-compliant temperature control – air & mass can be controlled separately
• choose your welding shoe via our welding shoe selection helper or the pdf ordering form

Item Number
Max. Output 4,8 kg/h, Ø 5mm // 3,2 kg/h, Ø 4 mm
Welding Material PP/PE/PVDF Ø 5 / 4 mm
Application wall thickness 10 – 35 mm
Separately controlled mass and air temperature yes (DVS)
Heating tape power 650 W
Preheating fan power 2300W
Extruder motor/fan motor brushed/brushless
Powerbox not necessary
Power Supply 240V 50Hz/60Hz
Power cord length 7,5m
Weight 8,7 kg
Length 570 mm

B container construction version: side-mounted preheating
D geosynthetics version: top-mounted preheating
