• powerful and yet lightweight - more output, more power
• DVS-compliant temperature control – air & mass can be controlled separately
• choose your welding shoe via our welding shoe selection helper or the pdf ordering form

Item Number
Max. Output 5,8 kg/h, Ø 5mm // 3,8 kg/h, Ø 4 mm
Welding Material PP/PE/PVDF Ø 5 / 4 mm
Application wall thickness 12 – 40 mm
Separately controlled mass and air temperature yes (DVS)
Heating tape power 650 W
Preheating fan power 2300W
Extruder motor/fan motor brushed/brushless
Powerbox not necessary
Power Supply 240V 50Hz/60Hz
Power cord length 7,5m
Weight 10,2 kg
Length 799 mm

B container construction version: side-mounted preheating
D geosynthetics version: top-mounted preheating
